12 AWG 600 Volt Solar Wire
12 AWG 600 Volt Solar Wire
The Characteristics of 600 Volt Wire
Application:
The 12 AWG 600 Volt Solar Wire is mainly used in solar applications with a solar system rated voltage of 600volt. For connecting and interconnecting solar system components.
12 AWG 600 Volt Solar Wire Standard:
Compliant with double certification standards such as international TUV and CE
12 AWG 600 Volt Solar Wire Electrical Parameters:
Voltage Rating : AC 0.6 / 1.0 kV Max. PV
System Voltage : DC up to 2.0 kV possible Max.
Permissible Operating Voltage in AC Systems : 0.7 / 1.2 kV Max. Permissible Operating Voltage in DC Systems : 0.9 / 1.8 kV
Test Voltage : AC 6 kV / DC 10 kV (15 min.)
12 AWG 600 Volt Solar Wire Construction:
Conductor: Tinned fine copper strands acc.to VDE
0295/IEC 60228, Class 5.
Insulation:XLPO, flame retardant, halogen free
electron-beam cross-linked.
Jacket: XLPO, flame retardant, halogen free, electron-beam cross-linked.
Insulation color :black
Jacket color :black or red
600 Volt Wire Advantage:
The 600 Volt Solar Wire operates at high temperatures and is exposed to various harsh outdoor environments. Its superior wear resistance and anti-aging, UV resistance and other characteristics make it ideal for outdoor use as well as harsh environments.
600 Volt Wire is manufactured for use in photovoltaic applications, while USE-2 cable types are typically manufactured for underground service entrance applications.
Both cable types commonly contain XLPE insulation and can be sunlight resistant and/or rated for direct burial.
Product Specifications
n×mm2 | n×mm | MM | MM | Ω/KM |
1×1.5 | 30×0.25 | 1.58 | 4.90 | 13.3 |
1×2.5 | 50×0.256 | 2.06 | 5.45 | 7.98 |
1×4.0 | 56×0.3 | 2.58 | 6.15 | 4.75 |
1×6 | 84×0.3 | 3.15 | 7.15 | 3.39 |
1×10 | 142×0.3 | 4.0 | 9.05 | 1.95 |
1×16 | 228×0.3 | 5.7 | 10.2 | 1.24 |
1×25 | 361×0.3 | 6.8 | 12.0 | 0.795 |
1×35 | 494×0.3 | 8.8 | 13.8 | 0.565 |
1×50 | 418×0.39 | 10.0 | 16.0 | 0.393 |
1×70 | 589×0.39 | 11.8 | 18.4 | 0.277 |
1×95 | 798×0.39 | 13.8 | 21.3 | 0.210 |
1×120 | 1007×0.39 | 15.6 | 21.6 | 0.164 |
FAQ:
What is 600 Volt Wire used for?
600V Wire is uesed for solar, residential, commercial, and industrial lighting and power.
What is size is 600 Volt Wire?
The size is from 16 AWG to 1000 MCM, 1.0sqmm to 240sqmm. Can be directly buried, free air, pipes, underground pipes.
Do you have 600 Volt Wire in stocK?
Yes, we have 600V wire in stock. Just tell me your request, I will choose the right cable for you.
