pv1-f solar pv cable
what is pv1-f
pv1-f is a type of photovoltaic wire, the conductor of photovoltaic cable pv1-f conforms to IEC 60228, class 5 tinned copper stranded wire
closed flexible conductor
Product Specifications put up
Conductor: tinned fine copper stranded wire according to VDE 0295/IEC 60228, Class 5.
Insulation: XLPO, flame retardant, halogen free Electron beam crosslinking.
Sheath: XLPO, flame retardant, halogen free, electron beam crosslinked.
Insulation Color: Black
Jacket Color: Black or Red
Electrical Characteristics
Rated voltage: DC 1500 V AC Uo/U: 1.0/1.0 kV
Maximum allowable voltage: Uo 1800 V DC
Insulation resistance: 1000MΩ/KM
Test voltage (AC): AC 6. 5kV, 50Hz, 5 min
Mechanical properties
Bending radius: 4 x outer diameter
Temperature range: -40℃ to +90℃, Max.temp. at conductor +120℃
Short circuit temperature: 250℃ for 5 seconds
Flame retardant test: according to EN 60332-1-2
Expected service life: 35 years
Product Specifications
Model name structure (mm/mm) Model name is diameter (mm) Insulation thickness (mm) Sleeve thickness (mm) 20°C (mm)
specifications of the products
型号 | 标称截面（mm²） | 导体结构（mm） | 导体直径（mm） | 绝缘厚度（mm） | 护套厚度（mm） | 电缆直径（mm） | 电流电阻为20℃(Ω/km) |
PV1-F | 1.5 | 30/0.2 | 1.6 | 1.0 | 0.8 | 5.2 | 12.2 |
PV1-F | 2.5 | 50/0.2 | 2.0 | 1.0 | 0.8 | 5.6 | 7.56 |
PV1-F | 4 | 56/0.3 | 2.6 | 1.0 | 0.9 | 6.4 | 4.7 |
PV1-F | 6 | 84/0.3 | 3.2 | 1.0 | 0.9 | 7 | 3.11 |
PV1-F | 10 | 142/0.41 | 4.4 | 1.0 | 0.9 | 8.2 | 1.84 |
PV1-F | 16 | 228/0.41 | 5.5 | 1.0 | 1.1 | 9.7 | 1.16 |
PV1-F | 25 | 361/0.41 | 6.5 | 1.2 | 1.2 | 11.3 | 0.734 |
PV1-F | 35 | 525/0.41 | 7.5 | 1.2 | 1.2 | 12.3 | 0.529 |
Other photovoltaic module products
